CHAND COMPANY - Plain Clamp

DIGITAL CALIPER

Resolution: 0.01mm/0.0005"
Model No.: 1112-150
Price : 1586
Model No.: 1112-200
Price : 2409
Model No.: 1112-300
Price : 4428

VERNIER CALIPER

Graduation:0.02mm/0.001
Model No.: 1205-1502
Price : 1185

DIAL CALIPER

Graduation: 0.01mm
Model No.: 1312-150A
Price : 2103
View

DIGITAL HEIGHT GAUGE

Resolution: 0.01mm/0.0005"
Model No.: 1150-300
Price : 11843

DIAL INDICATOR

Graduation:0.01mm
Model No.: 2301-10
Price : 1210

Dial Test Indicator

Graduation: 0.01mm
Model No.: 2380-08
Price : 2178

BORE GAUGE

Repeatability:0.003mm
Model No.:2322-35A
Price : 4913

Model No.:2322-60A
Price : 4914

Model No.:2322-160A
Price : 5101

MAGNETIC STAND

For digital/dial indicators and dial test indicators
Model No.: 6201-60
Price : 861

Fluke 771 Milliamp Process Clamp Meter
Save time by NOT breaking the loop on 4-20 mA signal measurements.

Taking mA measurements by removing a wire and breaking the loop

Calling the control room to isolate a loop

Testing analog input/output on a console

Troubleshooting devices with mA inputs and outputs

Repairing intermittent or erratic 4-20 mA loops

Going back to the shop to get extra tools

SR.	Fluke CODE	Price In Rs.
1	771	43,200

Specifications
Diameter of measurable conductor	0.177” or 4.5 mm max
Operating temperature	-10 to 50 ºC
Storage Temperature	-25 to 60ºC
Operating Humidity	< 90% @ <30 ºC, < 75% @ 30 to 55ºC
Operating Altitude	0 to 2000 m
IP Rating	IP 40
Size	59 x 38 x 212 mm, (2.32 x 1.5 x 8.35 in.)
Weight	260G, (9.1 oz.)
Vibration	Random 2 g, 5 to 500 Hz
Shock	1 meter drop test (except the jaw)
EMI/RFI	Meets EN61326-1 Note: For current measurement w/ JAW, add 1mA to specification for EMC field strengths of 1V/m up to 3V/m.
Temperature Coefficient	0.01% ºC (<18? or > 28?)
Power, battery life	(2) AA 1.5 V Alkaline, IEC LR6, 40 hours typical
Warranty	Three years for electronics one year for cable and clamp assembly
mA measurement (Measured by clamp)	Resolution and Range: 0 to 20.99 mA Accuracy: 0.2% +2 counts Resolution and Range: 21.0 mA to 100.0 mA Accuracy: 1% + 5 counts
